Coil Processing Unit

4 IN 1 COIL PROCESSING UNIT

Heavy duty coil feeding lines for Press Feed equipments

  • Uncoiler with manual / hydraulic jaw expansion and variable drive & loop control system.
  • Straightening and feed rolls hardened and hard chrome plated
  • Roll baskets along with threading table to assist and support the threading of coil material
  • Hydraulic / pneumatic hold-down, snubber and piller for threading is available on request.
  • Optional Coil car is available on request.
  • Coil width guide manual/automatic
  • Models uptill 1300 mm width and thickness uptill 8 mm is available on request.
  • Feed Height adjustment is provided.
  • Coil tip flattener roller is available on request.
  • 4 in 1 coil processing unit

    Control Panel with Touch Screen Programming for simplicity in Parameters feeding

    Specifications :

    Model C-400 C-600 C-800
    Parameters
    Width (mm) 400 mm 600 mm 800 mm
    Thickness (mm) 0.7 - 4.5 mm 0.8 - 6.0 mm 0.8 - 6.0 mm
    Max Coil Weight 3000 Kg 5000 Kg 5000 Kg
    Straitening Capacity / Width 4.5 x 200 mm 2.5 x 600 mm 2.5 x 600 mm / 2.0 x 800 mm
      3.0 x 400 mm 6.0 x 300 mm 6.0 x 300 mm
    Coil OD 1500 mm 1500 mm 1500 mm
    Coil ID 508 508 508
    Features Coil Car,
    Hydraulic Expansion,
    Snubber, Piller,
    Pre-Pinch,
    Auto Side Guide,
    Pressure Roller,
    Hydraulic Power Pack.
    Coil Car,
    Hydraulic Expansion,
    Snubber, Piller,
    Pre-Pinch,
    Auto Side Guide,
    Pressure Roller,
    Hydraulic Power Pack.
    Coil Car,
    Hydraulic Expansion,
    Snubber, Piller,
    Pre-Pinch,
    Auto Side Guide,
    Pressure Roller,
    Hydraulic Power Pack.
    Line Speed (Max) 15 15 15

    The above parameters are for the material having tensile strength 40kgf/mm² max.

    Models of higher capacity or higher or lower line speeds are available on request.

    Technical specifications are indicative and subject to change to suit end application.
